Drawbar trailer
Category：
Product center
Drawbar trailer
Brief description
Key words:
Detailed description
Full Trailer Type: 2/3 Axle Drawbar Small Trailer 1 Piece (Minimum Order)
Type: Loading Capacity: 30T
Certification: ISO9001, CCC, SGS BV
Wheelbase: 7000-8000mm
Pedals: 1820mm
Customized: Customized request, drawbar trailer, independent suspension, wishbone
Shape: van
Axle number: 2 or 3
Tire Size: 8/12
Self-dumping, non-self-dumping, ABS anti-lock braking system, ABS anti-lock braking system
Material: Steel
health status: new
Delivery Time: Ships within 15 days after payment
Color: customer request
Shaft: 13 tons Fuwa/BPW
Suspension: Leaf Spring Suspension
Tire: 11.00r20 12r22.5 315 385
Tie Rod: Size as required
Electronic system: 1. Voltage: 24V 2. Socket: 7 way (7 wire harness)
Shipping package: N/M, nude, or as copper
Specifications: customer requirements
Trademark: Aotong
Origin: Shandong, China (Mainland)
HS code
Production capacity: 300 sets per month
Product description: A direct factory for all kinds of high-quality semi-trailers
1. 15 years experience manufacturer 2. CCC, ISO, SGS, BV agree 3. Well-designed, accept small orders 4. Manufactured according to your detailed requirements 5. After-sales support; 6 months warranty
Full Trailer Type 2/3 Axle Drawbar Small Trailer For Sale
Dimensions (L*W*H) (6000-17000)*2500*1550mm
Rated load 30T-80T
Tare 7000 kg
Wheelbase 8390+1310+1310 (mm)
Tire Specification 11.00R20/12R22.5/315/385
Spare tire holder 1 or 2
Axle Brand FUWA (BPW optional)
Number of axes: 2/3/4
Axle load 13000 kg
Brake Brand TKL Brand
Brake chamber Double air chamber
System Dual-line braking system/ABS
Main beam material I-beam, Q345B, automatic submerged arc welding
Specifications Height 500mm, upper plate 14mm, lower plate 16mm, middle plate 8mm
Beam material Q235B
Side beam Channel steel
Plate shape Steel plate 3mm thickness or diamond plate (other thicknesses can also be selected, such as 2mm, 2.3mm, 4mm, 5mm, 6mm)
Accessories A toolbox with a standard set of trailer tools
Voltage 24V
Container 7-way (7 harness)
Lights Front corner marker light: red; reflector light: white
Side Marker: Orange
Rear light: red; rear reflector: white; turn single light: orange
Packaging and Shipping
We transport semi-trailers in bulk or in containers. Our factory has long-term cooperation with shipping agents and can provide you with the lowest freight.
